Salicru SLC-2000-TWIN PRO2 B1 IEC

SKU 699CA000018

Price on application

Salicru’s SLC TWIN PRO2 series is a UPS range in a tower format equipped with on-line double-conversion technology and the latest features to make it an advanced protection system for sensitive and critical loads. High output power factor (PF=0.9) to ensure availability to all types of loads. Full c

Description

High output power factor (PF=0.9) to ensure availability to all types of loads.

Full control through status information via LCD display and keypad.

And extensive monitoring and communication options via the built-in USB HID interface, an intelligent slot for SNMP cards or relays and a wide range of software packages available – free monitoring version downloadable for Windows, Linux, Unix or Mac and packages available for multi servers or virtualised systems.

For facilities that require more back-up time, there is a possibility of backup extensions using UPSs with extra charger and additional battery modules.

Also notable is the possibility of Eco-mode operation to improve the efficiency of the device, EPO (emergency power off) functions, operation as a frequency converter and built-in battery test.

Salicru’s SLC TWIN PRO2 range is available in power ratings of 700, 1000, 1500, 2000 and 3000 VA.

Specifications

Power Output voltage regulation: 1%
Output frequency regulation: 0.5
Hz Output power factor: 0.9
Input power factor: 0.99
Output power: 1800 W
Input operation voltage (min): 220 V
Input operation voltage (max): 240 V
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Emergency Power Off (EPO) Yes Output voltage Total Harmonic: Distortion (THD) 2%
Input current Total Harmonic Distortion (THD): 2%
Crest factor: 3 1
Output power capacity: 2000
VA Efficiency (On-line mode): 92%
Efficiency (ECO mode): 98%
ECO mode Yes Battery Battery: type

AGM

Off-mode charging Yes Battery technology Lead-Calcium (Pb-Ca) Battery recharge: time 4 h
Automatic battery test Yes Performance Audible alarm modes Alarm: when on battery, Fault,
Low battery alarm UPS topology Double-conversion (Online) Waveform Pseudo: sine
Off-mode charging Yes Number of output phases: 1
Number of input phases: 1
LED indicators Yes Surge protection Yes Power protection features: Under voltage
Noise level: 49 dB
Audible: alarm(s)
Yes Overload capacity (1 minute): 130%
Features Audible alarm modes Alarm when on: battery, Fault,
Low battery alarm UPS topology Double-conversion (Online) Waveform Pseudo: sine
Output voltage regulation: 1%
Output frequency regulation: 0.5
Hz Number of output phases: 1
Number of input phases: 1
Output power factor: 0.9
Input power factor: 0.99
Output power: 1800 W
Input operation voltage (min): 220 V
Input operation voltage (max): 240 V
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Surge protection Yes Emergency Power Off (EPO) Yes Power: protection features
Under voltage Output voltage Total Harmonic Distortion (THD): 2%
Noise level: 49 dB
Input current Total Harmonic Distortion (THD): 2%
Crest factor: 3:1
Audible: alarm(s)
Yes Output power capacity: 2000
VA Overload capacity (1 minute): 130%
Efficiency (On-line mode): 92%
Efficiency (ECO mode): 98%
ECO mode Yes Input frequency: 50/60
Hz Ports: & interfaces
Emergency Power Off (EPO) connector Yes USB port Yes: AC outlets quantity 4
AC: outlet(s)
AC outlet types C13: coupler,

IEC

Jumpers Power plug C19 coupler USB: 2.0 ports quantity 1
Number of output IEC jumpers: 4
Design Form factor Tower LED indicators Yes Product colour: Black
Safety EN: 62040-1:2008+A1:2013 Display

LCD

Cooling type Active Certification EN: 62040-2
EN: 62040-3
ISO-9001 ISO-14001 Built-in fan Yes Operational conditions Operating temperature: (T-T) 0 – 40 C
Operating relative humidity (H-H): 0 – 95%
Operating altitude: 0 – 2400 m
Cooling Cooling type Active Built-in fan Yes Weight: & dimensions
Weight: 18.4 kg
Width: 190 mm
Height: 327 mm
Depth: 399 mm
Certificates Safety EN: 62040-1:2008+A1:2013
Certification EN: 62040-2
EN: 62040-3
ISO-9001 ISO-14001 Other features Battery type AGM: | Power |
Output voltage regulation: | 1% |
Output frequency regulation: | 0.5 Hz |
Output power factor: | 0.9 |
Input power factor: | 0.99 |
Output power: | 1800 W |
Input operation voltage (min): | 220 V |
Input operation voltage (max): | 240 V |
Output operation voltage (min): | 220 V |
Output operation voltage (max): | 240 V |
Emergency Power Off (EPO): | Yes |
Output voltage Total Harmonic Distortion (THD): | 2% |
Input current Total Harmonic Distortion (THD): | 2% |
Crest factor: | 3:1 |
Output power capacity: | 2000 VA |
Efficiency (On-line mode): | 92% |
Efficiency (ECO mode): | 98% |
ECO mode: | Yes | Battery |
Battery type: | AGM |
Off-mode charging: | Yes |
Battery technology: |
Lead-Calcium (Pb-Ca): |
Battery recharge time: | 4 h |
Automatic battery test: | Yes | Performance |
Audible alarm modes: |
Alarm when on: battery, Fault,
Low battery alarm: |
UPS topology: |
Double-conversion (Online): | Waveform |
Pseudo sine: |
Off-mode charging: | Yes |
Number of output phases: | 1 |
Number of input phases: | 1 |
LED indicators: | Yes |
Surge protection: | Yes |
Power protection features: |
Under voltage: |
Noise level: | 49 dB |
Audible: alarm(s) | Yes |
Overload capacity (1 minute): | 130% | Features |
Audible alarm modes: |
Alarm when on: battery, Fault,
Low battery alarm: |
UPS topology: |
Double-conversion (Online): | Waveform |
Pseudo sine: |
Output voltage regulation: | 1% |
Output frequency regulation: | 0.5 Hz |
Number of output phases: | 1 |
Number of input phases: | 1 |
Output power factor: | 0.9 |
Input power factor: | 0.99 |
Output power: | 1800 W |
Input operation voltage (min): | 220 V |
Input operation voltage (max): | 240 V |
Output operation voltage (min): | 220 V |
Output operation voltage (max): | 240 V |
Surge protection: | Yes |
Emergency Power Off (EPO): | Yes |
Power protection features: |
Under voltage: |
Output voltage Total Harmonic Distortion (THD): | 2% |
Noise level: | 49 dB |
Input current Total Harmonic Distortion (THD): | 2% |
Crest factor: | 3:1 |
Audible: alarm(s) | Yes |
Output power capacity: | 2000 VA |
Overload capacity (1 minute): | 130% |
Efficiency (On-line mode): | 92% |
Efficiency (ECO mode): | 98% |
ECO mode: | Yes |
Input frequency: | 50/60 Hz | Ports & interfaces |
Emergency Power Off (EPO) connector: | Yes |
USB port: | Yes |
AC outlets quantity: | 4
AC: outlet(s) |
AC outlet types: | C13 coupler,

IEC

Jumpers: |
Power plug: | C19 coupler |
USB: 2.0 ports quantity | 1 |
Number of output IEC jumpers: | 4 | Design |
Form factor: | Tower |
LED indicators: | Yes |
Product colour: | Black | Safety |
EN: 62040-1:2008+A1:2013 | Display | LCD |
Cooling type: | Active | Certification |
EN: 62040-2
EN: 62040-3
ISO-9001 ISO-14001: |
Built-in fan: | Yes |
Operational conditions: |
Operating temperature (T-T): | 0 – 40 C |
Operating relative humidity (H-H): | 0 – 95% |
Operating altitude: | 0 – 2400 m | Cooling |
Cooling type: | Active |
Built-in fan: | Yes | Weight & dimensions | Weight | 18.4 kg | Width | 190 mm | Height | 327 mm | Depth | 399 mm | Certificates | Safety |
EN: 62040-1:2008+A1:2013 | Certification |
EN: 62040-2
EN: 62040-3
ISO-9001 ISO-14001: |
Other features: |
Battery type: | AGM
